NM-WGN
Wagon-Jig for multi-point harness testing
Wagon-type rack for storing multi-point harness testers NMF (~4096 points) and converting them to general purpose connectors.
The harness tester, jig panels, and optional products are integrated into NM-WGN, making it easy to operate multi-point testing systems.
Improve the efficiency of multi-point testing, such as in the automotive and railroad industries.
JPY 1,244,600 ~ 2,688,600
Contact us for delivery date
Harness tester NMF & relay jig are installed together in a wagon-type facility
In multi-point testing, it is common to convert to general-purpose connectors that are easy to insert and remove with jigs. As an example, it can be converted to ITT CANNON, HIROSE, JAE, etc. to reduce the stress of testing. NM-WGN can be easily moved to get closer to the target for testing.
How to Operate Cable Harness Testers in Stand-Alone
This video will show you how to operate the Cable Harness Testers in Stand-Alone. You can check the preparation of test data by sampling, test the cables, and the settings. This video can also be used for confirmation when considering the introduction of the Cable Harness Testers and for training the operators.
FAQMounting Connector
| ITT CANNON | DL3-60R (60pts) |
|---|---|
| HIROSE | Sumicon1660 (60pts) |
| JAE | Dsub 50 (50pts) |
Document
| NM-WGN Specification | Download |
|---|
